57-35

Item No. 57-35

MAIN DIMENSIONS AND STANDARD PARTICULARS
Type	57-35
Creepage Distance/mm	1143
Dry Arcing Distance/mm	438
Cantilever Strength/kn	12.5
Low Frequency Dry Flashover Voltage/kv	160
Low Frequency Wet Flashover Voltage/kv	130
Critical Impulse Flashover Voltage, Pos/kv	265
Critical Impulse Flashover Voltage, Neg/kv	380
Test Voltage to Ground/kv	44
Maximum RIV at 1000KHZ/μv	200
Net Weight/kg	21.5
Applicable standard	ANSI
